| Compressor Flow Map | Turbine Flow Map | Turbo afmetingen |
Specificaties:
| Compressor | Turbine | Art.nr. | |||||||||||
| Wh Dia | Trim | In | Out | A/R | Wh Dia | Trim | In | Out | A/R | Type | |||
| Ind | Exd | Ind | Exd | ||||||||||
| 61.4mm | 82.0mm | 56 | 103.6mm | 51mm | 0.70 | 60.0mm | 54.8mm | 84 | |||||
| T3 | 4 bolt | 0.63 | non-wastegated | 740902-3 | |||||||||
| T3 | 4 bolt | 0.82 | non-wastegated | 740902-2 | |||||||||
| T3 | 4 bolt | 1.06 | non-wastegated | 740902-1 | |||||||||
| T3 | V-band | 0.63 | non-wastegated | 740902-9 | |||||||||
| T3 | V-band | 0.82 | non-wastegated | 740902-8 | |||||||||
| T3 | V-band | 1.06 | non-wastegated | 740902-7 | |||||||||
| T4 | V-band | 0.63 | non-wastegated | 740902-15 | |||||||||
| T4 | V-band | 0.82 | non-wastegated | 740902-14 | |||||||||
| T4 | V-band | 1.06 | non-wastegated | 740902-13 | |||||||||
| Compressor | Turbine | Art.nr. | |||||||||||
| Wh Dia | Trim | In | Out | A/R | Wh Dia | Trim | In | Out | A/R | Type | |||
| Ind | Exd | Ind | Exd | ||||||||||
| 61.4mm | 82.0mm | 56 | 103.6mm | 51mm | 0.70 | 60.0mm | 54.8mm | 84 | |||||
| T3 | 4 bolt | 0.63 | non-wastegated | 740902-3 | |||||||||
