| Compressor Flow Map | Turbine Flow Map | Turbo afmetingen |
Specificaties:
| Compressor | Turbine | Art.nr. | |||||||||||
| Wh Dia | Trim | In | Out | A/R | Wh Dia | Trim | In | Out | A/R | Type | |||
| Ind | Exd | Ind | Exd | ||||||||||
| 67.8mm | 94.0mm | 52 | 101.6mm | 63mm | 0.72 | 77.0mm | 78 | 751470-19/22 | |||||
| Divided T4 | V-band | 0.85 | non-wastegated | 448375-22 | |||||||||
| Divided T4 | V-band | 0.95 | non-wastegated | 448375-21 | |||||||||
| Divided T4 | V-band | 1.06 | non-wastegated | 448375-20 | |||||||||
| Divided T4 | V-band | 1.19 | non-wastegated | 448375-19 | |||||||||
